[TRA7207] 1/16 Summit VXL 4WD Electric Monster White

 This is the brushless electric powered, 2.4GHz radio controlled, ready to run
                 1/16 scale Traxxas Summit VXL Monster Truck.

FEATURES: Chassis: Nylon composite construction 0.08" (2mm) thick monocoque
            type
          Drive: Four wheel
          Radio: Traxxas TQ 2.4GHz high output with Traxxas Link for easy model
            recall, mini receiver and waterproof micro steering servo
          Electronic Speed Control: Traxxas VXL-3m waterproof, with high-
            current connector, training mode, reverse and low voltage
            detection for use with 2S and 3S LiPo packs
          Motor: Traxxas Velineon 380 brushless, 8 turn 4000kV with Neodymium
            magnets, sintered rotor and high RPM ball bearings, 3.5mm gold
            plated bullet connectors
          Spur Gear: 45 tooth
          Pinion Gear: 16 tooth 48 pitch
          Battery: One Traxxas Power Cell 1200mAh 6-cell NiMH w/high current
            connector, dual NiMH battery capability (extra battery (TRAC2925)
            and series adapter (TRAP3063) not included and must be purchased
            separately).
            Vehicle is also compatible with one 2S or 3S LiPo pack (not
            included) LiPo mode on ESC must be selected.
            **NOTE the ESC and motor CANNOT handle dual LiPos, if using dual
           batteries, both must be NiMH.**
          Battery Charger: 110V wall type
          Body: Painted and trimmed with applied decals
          Bumpers: Front and rear, composite construction
          Shocks: GTR oil filled
          Suspension: Revo-spec rocker actuated long travel inboard type with
            telescoping universal joint shafts
          Transmission: Single speed ball bearing equipped with adjustable
            slipper clutch
          Differentials: Sealed silicone filled planetary steel bevel gears
          Ball Bearings: Rubber sealed
          Caster: Non-adjustable
          Camber: Adjustable, camber refers to the angle of the tops of the
            tires from vertical when viewed from front or behind vehicle
          Tires: Multi terrain, with large angular lugs and foam inserts
          Wheels: 2.2" (56mm) diameter Geode, chrome finish with painted
            beadlock style rims, standard size 12mm hex
          Steering: Bellcrank with spring loaded servo protection

INCLUDES: RTR Traxxas Summit VXL Monster Truck with 2.4GHz 2-ch radio, micro
            steering servo, ESC, painted body, 6-cell battery, charger,
            brushless motor and instruction manual

REQUIRES: AA Cells: Four for transmitter

SPECS:      Vehicle-
          Length: 14" (356mm)
          Height: 7.48" (190mm)
          Front Track: 10.43" (265mm)
          Rear Track: 10.63" (270mm) distance between outer edges of wheels
            side-to-side
          Weight: 44oz (1.24kg)
          Wheelbase: 8.425" (214mm)
          Ground Clearance: 2.75" (70mm)
          Internal Gear Ratio: 5.04:1 (reversed input: 9.72:1)
          Overall Drive Ratio: 15.75 (stock, out of box)
            Body-
          Length: 11.4" (291mm)
          Width:   5"   (127mm)
          Height:  3.6" (92mm) measured at light bar

COMMENTS: If wanting to upgrade to a battery with a slightly higher mAh rating,
            the DuraTrax 1600mAh NiMH 7.2V 6-Cell Battery (DTXC2192) is an
            ideal choice.

          The ball bearings in the Traxxas Summit VXL are rubber sealed.
          Following are the stock numbers for the replacement bearings from
            Traxxas and non-rubber sealed alternatives from Duratrax;
            Qty.  Size         Location             Qty.    Bearing Set
             2   8x12mm      Fr Drivshaft            1    TRAC7020   DTXC1581
             2   4x8mm       Fr Hubs                 1    TRAC7019   DTXC1511
             2   8x12mm      Rear Drivshaft          1    TRAC7020   DTXC1581
             2   4x8mm       Rear Hubs               1    TRAC7019   DTXC1511
             2   5x8mm       Steering Bellcrank      1               DTXC1523
             2   4x7mm       Rocker Arm Post         2               DTXC1507
             4   8x12mm      Differentials           2    TRAC7020   DTXC1581
             4   4x8mm       Differentials           2    TRAC7019   DTXC1511
             6   4x8mm       Transmission            3    TRAC7019   DTXC1511
             2   4x8mm       Rear Ring Gear          1    TRAC7019   DTXC1511

          Available in the following body colors;
            Blue,   TRAD30BB          White,  TRAD30WW
            Red,    TRAD30RR          Yellow, TRAD30YY
